A machine that secures time doing wrapping process is used effectively and efficiently with its built-in measuring scale. This eliminates non-productivity as it can simultaneously wrap the pallet that is supposed to be packaged as well as weigh the boxes after as needed. Promoting a stress-free packing and weighing at a practical cost.
Heighten the rate of productivity with the E3 WRAP 2100 SCALE, a wrapping equipment that does packaging and weighing of pallets at the same time. Equipped with a weighing scale of up to 2000kg. Also designed with an ergonomic concept, the E3 series also has a free space no blockage feature – Pallets are placed directly on the floor hence no lifting, pulling, or pushing of heavy bulky boxes, all keeping workers comfortable and productive. This machine is a good call for small to large scale businesses for small to heavy duty pallet wrapping needs.
Taking you to the next level with its:
1. Lightweight Eco-Friendly Machine: Designed with recyclable materials of about 95%
2. No ramp, no hill, no blockage: No need for turn tables hence there won’t be any pushing or pulling of pallets for wrapping purposes
3. No Package Weight Limit: As pallets are situated on the floor without any ramp, package weight is boundless
4. Easy to Operate: Equipped with a Mini PLC. Standard program of top and button wraps can be modified using the PLC with the aid of a programming cable item no. 95081884 if to be adjusted by operator. Download of required software is free when purchased
5. Height Detection
6. Pre-Stretch with Photocell: Film is stretched to its potential competence hence saving material and reducing cost, a 100% extra stretching is upon demand (PLUS 100).
7. Speed: Ensuring to wrap pallets at a speed of 25 – 500 pallets/week, this is also perfect for packing standard pallets:
a. EURO Pallet: 800mm x 1200mm
b. US Pallet: 1000mm x 1200mm
c. Industrial Pallet: 1350mm x 950mm
8. Film Roll Specifically made for E3 WRAP 2100: A film roll of 750mm wide on a ø38mm core saves you film, transport cost, and transport time. Rolls also weighs less than 12kg to a standard of 17kg for lifting ease
9. 5 Level Safety System: Includes an emergency stop safety system for preventing hazards to personnel welfare. Rotary arm will ensure stop when operator would get in the way even during motion
10. Easy to install: A wall-mounted stretch film wrapper
11. CE and ROHS compliant
| SPECIFICATIONS: | |
| Dimension when installed (HxBxD/Ø) | 2800mm x 2255mm x 2450mm/Ø2225mm |
| Space needed when parked | 400mm x 600mm |
| Maximum pallet size (standard) | 1200mm x 1200mm x 2200mm, no weight limit |
| Turning Diameter (standard) | 1910mm, 360⁰ Full Access |
| Speed | 2200mm high pallet, approximately 90 seconds1000mm high pallet, less than 60 seconds |
| Power | 110 V to 230 V, 60/50 Hz |
| Pallet Demand | Low pallet, approx.1000mm, approx. 55-60 seconds per pallet |
| High pallet, approx. 1800mm, approx. 105-110 seconds per pallet | |
| Wraps Standard Pallet | EURO Pallet: 800mm x 1200mm |
| US Pallet: 1000mm x 1200mm | |
| Industrial Pallet: 1350mm x 950mm | |
| E3 Wrap Film Size (Width and Core) | 750mm ø38mm core |
| Standard Program Wraps | Button Wraps: 1 at the beginning and 1 at the end, 2 in total |
| Top Wraps: 1 top wrap | |
| Machine Net Weight | 56kg |
Options:
• Pallet height 2700mm/3000mm
• Motor controller for overlap adjustment
• Adaptor for handwrap Ø50 x 450/500mm
• POLE H3000mm, for floor mounting, or for higher as option
• PLUS 25 aggregate, 25% pull through pre stretch (see E3 WRAP 2100 PLUS)
• Dual Wrapping Needs (see E3 WRAP 2100 DUO)
• Large Diameter Needs of 2500mm, pallet 2000x600mm (see E3 WRAP 2100 LARGO)
• Special applications on demand
Available in different models:
• E3 WRAP 2100 STANDARD
• E3 WRAP 2100 PLUS
• E3 WRAP 2100 DUO
• E3 WRAP 2100 LARGO
Installation (if desired):
• Installation and/or service contract has a set of terms and price, kindly contact us for more information
